We manufacture Accessories under technical guidance. The important Accessories are viz…
|
Labyrinth sealing – is used as armor against abrasive environment and works as ‘grease purge’ seals. |
|
Output hubs - are produced to provide positive drive with a key way and no fretting corrosion. |
|
Extraction collars – are put on to extract the gear unit from the shaft. |
|
Shaft mounted units are accessible with hydraulic motor interface. |
|
Reducing bushes – are available in various sizes in steels and stainless steels. |
|
Safety covers exist at non conveyor end. |
|
|
| |
|
| |
| Bushø |
Bores Available |
| 30 |
25, 20 ¾", 1" |
| 40 |
35, 32, 30 1¼" |
| 50 |
45, 42, 40, 38 1¾", 1½", 1¼" |
| 55 |
50, 45, 42 2", 1 ¾", 1½" |
| 65 |
60, 55, 50 2¼", 2" |
| 75 |
70, 65, 60 2¾". 2½", 2¼" |
| 85 |
80, 75, 70 3", 2¾", 2½" |
| 100 |
95, 90 3½" |
| 120 |
110, 100, 90 4½", 4, 3½" |
|
| |
| Size |
A |
A |
B |
C |
METRIC MOTOR FRAME SIZE |
| MIN. |
MAX. |
MIN. |
MAX. |
| B |
210 |
265 |
165 |
220 |
270 |
140 |
63, 71, 80, 90S, 90L |
| C |
260 |
330 |
200 |
270 |
370 |
190 |
63, 71, 80, 90S, 90L, 100L |
| D |
300 |
370 |
235 |
305 |
370 |
165 |
71, 80, 90S, 90L, 100L, 112M |
| E |
325 |
395 |
310 |
380 |
440 |
220 |
80, 90S, 90L, 100L, 112M, 132S, 132M |
| F |
345 |
415 |
300 |
370 |
440 |
345 |
112M, 132S, 132M, 160M, 160L |
| G |
375 |
425 |
300 |
370 |
520 |
340 |
112M, 132S, 132M, 160M, 160L, 180M, 180L |
| H |
470 |
540 |
410 |
480 |
560 |
325 |
132S, 132M, 160M, 160L, 180M, 180L |
| J |
570 |
645 |
465 |
535 |
510 |
365 |
132M, 160M, 160L, 180M, 180L, 200L |
| S |
615 |
685 |
545 |
615 |
590 |
360 |
160M, 160L, 180M, 180L, 200L, 225S, 225M |
|
| |
|
| |
|
 |
|
|
