The gear units are available in Imperial bores and keyways. |
|
CEMA bolt on adaptor flanges features double lip seals on both sides. |
|
The adaptor center is open for contaminate to drop out for optimized sealing. |
|
3 – Holes drilled drive shafts are available in various sizes. |
Click here to download SMGU brochure . | Size | A1 | B1 HABØ |
C1 | D1 | E1 | F1 Ø |
F1 KEY WAY. |
M1 | W1 | L1 |
| B 1107 | 4.45 | 17/16 | 3.46 | 2.40 | 2.05 | ¾ | 1/8 x 1/8 | 3.35 | 3.62 | 3.22 |
| C 2115 | 4.65 | 115/16 | 3.66 | 2.48 | 2.17 | 15/16 | 3/16 x 3/16 | 3.54 | 3.82 | 3.56 |
| D 3203 | 5.16 | 23/16 | 4.41 | 2.76 | 2.40 | 11/8 | ¼ x ¼ | 3.94 | 4.13 | 3.62 |
| E 4207 | 5.67 | 27/16 | 5.70 | 3.07 | 2.60 | 11/8 | ¼ x ¼ | 4.11 | 4.64 | 4.00 |
| F 5215 | 6.45 | 215/16 | 5.90 | 3.50 | 2.95 | 1¼ | ¼ x ¼ | 4.60 | 5.04 | 4.00 |
| G 6307 | 7.54 | 37/16 | 6.14 | 4.00 | 3.54 | 1¾ | 3/8 x 3/8 | 5.15 | 5.98 | 5.50 |
| H 7315 | 8.39 | 315/16 | 6.34 | 4.45 | 3.94 | 115/16 | ½ x ½ | 5.78 | 6.69 | 6.47 |
| J 8407 | 8.73 | 47/16 | 7.28 | 4.60 | 4.13 | 2¼ | ½ x ½ | 6.10 | 7.71 | 6.47 |
