Shaft Mounted Taper Clamp Units


We have customized the Shaft Mounted Speed Reducer and designed a keyless gear unit. It is a quick release taper bushing and easier to install and remove that any comparable bushing system. The bushing comprises of a taper sleeve and threaded collar which ensures grater gripping power.

However, in order to prevent fretting corrosion and easy removal, shaft mounted taper clamps and the support bushes are manufactured in stainless steels. Taper clamps are available in various sizes of bores and securing easy method of mounting on different shaft sizes.

Please read our brochure to know more about the available accessories.
Click here to download SMGU brochure .

Size D2 M2 N2   BUSHES ØB
STD Other Available
B 78 84 162 30 20, 25, 1", ¾"
C 81 87 168 40 35, 32, 30, 1¼", 1½"
D 86 94 180 50 48, 45, 42, 40, 38, 1¼", 1½", 1¾"
E 92 102 194 55 50, 45, 42, 1½", 1¾", 2"
F 101 115 216 65 60, 55, 50, 2", 2¼", 2½"
G 112 123 235 75 70, 65, 60, 2¼", 2½", 2¾"
H 120 134 254 85 80, 75, 70, 2½", 2¾", 3"
J 130 145 275 100 90, 95, 80, 75, 3", 3½", 4"
S 155 169 324 120 110, 100, 95, 4¼", 4", 3½"
